Excel Like Filter in Blazor DataGrid Component

23 Aug 202311 minutes to read

You can enable Excel like filter by defining Type as Excel. The excel menu contains an option such as Sorting, Clear filter, Sub menu for advanced filtering.

@using Syncfusion.Blazor.Grids

<SfGrid DataSource="@Orders" AllowFiltering="true">
  <GridFilterSettings Type ="Syncfusion.Blazor.Grids.FilterType.Excel"></GridFilterSettings>
   <GridColumns>
     <GridColumn Field=@nameof(Order.OrderID) HeaderText="Order ID" TextAlign="TextAlign.Right" Width="120"></GridColumn>
     <GridColumn Field=@nameof(Order.CustomerID) HeaderText="Customer Name" Width="150"></GridColumn>
     <GridColumn Field=@nameof(Order.OrderDate) HeaderText=" Order Date" Format="d" Type="ColumnType.Date" TextAlign="TextAlign.Right" Width="130"></GridColumn>
     <GridColumn Field=@nameof(Order.Freight) HeaderText="Freight" Format="C2" TextAlign="TextAlign.Right" Width="120"></GridColumn>
   </GridColumns>
</SfGrid>

@code{
    public List<Order> Orders { get; set; }

    protected override void OnInitialized()
    {
        Orders = Enumerable.Range(1, 75).Select(x => new Order()
        {
            OrderID = 1000 + x,
            CustomerID = (new string[] { "ALFKI", "ANANTR", "ANTON", "BLONP", "BOLID" })[new Random().Next(5)],
            Freight = 2.1 * x,
            OrderDate = (new DateTime[] { new DateTime(2010, 5, 1), new DateTime(2010, 5, 2), new DateTime(2010, 5, 3), })[new Random().Next(3)],
        }).ToList();
    }

    public class Order {
        public int? OrderID { get; set; }
        public string CustomerID { get; set; }
        public DateTime? OrderDate { get; set; }
        public double? Freight { get; set; }
    }
}

The following screenshot represents Excel filter
Blazor DataGrid with Excel Filter

The following screenshot represents Custom filter in Excel filter
Blazor DataGrid Custom Excel Filter

Filter item template

This FilterItemTemplate helps to customize each CheckBox list element or value for display purposes. To access the checkbox list values inside the FilterItemTemplate, you can use the implicit named parameter context. You can type cast the context as FilterItemTemplateContext to get list values inside template.

@using Syncfusion.Blazor.Grids

<SfGrid DataSource="@Orders" AllowFiltering="true" AllowPaging="true" Height="375">
    <GridFilterSettings Type="Syncfusion.Blazor.Grids.FilterType.CheckBox"></GridFilterSettings>
    <GridColumns>
        <GridColumn Field=@nameof(Order.OrderID) HeaderText="Order ID" TextAlign="TextAlign.Right" Width="120"></GridColumn>
        <GridColumn Field=@nameof(Order.CustomerID) HeaderText="Customer Name" Width="150">
            <FilterItemTemplate>
                @{
                    var filterContext = (context as FilterItemTemplateContext);
                    var itemTemplateValue = "Textof(" + filterContext.Value + ")";
                }
                @itemTemplateValue
            </FilterItemTemplate>
        </GridColumn>
        <GridColumn Field=@nameof(Order.OrderDate) HeaderText=" Order Date" Format="d" Type="ColumnType.Date" TextAlign="TextAlign.Right" Width="130"></GridColumn>
        <GridColumn Field=@nameof(Order.Freight) HeaderText="Freight" Format="C2" TextAlign="TextAlign.Right" Width="120"></GridColumn>
    </GridColumns>
</SfGrid>

@code{
    public List<Order> Orders { get; set; }

    protected override void OnInitialized()
    {
        Orders = Enumerable.Range(1, 75).Select(x => new Order()
        {
            OrderID = 1000 + x,
            CustomerID = (new string[] { "ALFKI", "ANANTR", "ANTON", "BLONP", "BOLID" })[new Random().Next(5)],
            Freight = 2.1 * x,
            OrderDate = (new DateTime[] { new DateTime(2010, 5, 1), new DateTime(2010, 5, 2), new DateTime(2010, 5, 3), })[new Random().Next(3)],
        }).ToList();
    }

    public class Order
    {
        public int? OrderID { get; set; }
        public string CustomerID { get; set; }
        public DateTime? OrderDate { get; set; }
        public double? Freight { get; set; }
    }
}

Blazor DataGrid Filter with Item Template

Customize filter icon for filtered columns

After filtering the column, the DataGrid will display the in-built filtered icon with predefined styles by default. The filtered icon can also be customized using .e-grid .e-filtered::before class.

@using Syncfusion.Blazor.Grids

<SfGrid DataSource="@Orders" AllowFiltering="true">
    <GridFilterSettings Type="Syncfusion.Blazor.Grids.FilterType.Excel"></GridFilterSettings>
    <GridColumns>
        <GridColumn Field=@nameof(Order.OrderID) HeaderText="Order ID" TextAlign="TextAlign.Right" Width="120"></GridColumn>
        <GridColumn Field=@nameof(Order.CustomerID) HeaderText="Customer Name" Width="150"></GridColumn>
        <GridColumn Field=@nameof(Order.OrderDate) HeaderText=" Order Date" Format="d" Type="ColumnType.Date" TextAlign="TextAlign.Right" Width="130"></GridColumn>
        <GridColumn Field=@nameof(Order.Freight) HeaderText="Freight" Format="C2" TextAlign="TextAlign.Right" Width="120"></GridColumn>
    </GridColumns>
</SfGrid>

@code{
    public List<Order> Orders { get; set; }
    protected override void OnInitialized()
    {
        Orders = Enumerable.Range(1, 75).Select(x => new Order()
        {
            OrderID = 1000 + x,
            CustomerID = (new string[] { "ALFKI", "ANANTR", "ANTON", "BLONP", "BOLID" })[new Random().Next(5)],
            Freight = 2.1 * x,
            OrderDate = (new DateTime[] { new DateTime(2010, 5, 1), new DateTime(2010, 5, 2), new DateTime(2010, 5, 3), })[new Random().Next(3)],
        }).ToList();
    }
    public class Order
    {
        public int? OrderID { get; set; }
        public string CustomerID { get; set; }
        public DateTime? OrderDate { get; set; }
        public double? Freight { get; set; }
    }
}

<style>
    .e-grid .e-filtered::before {
        color: red;               // set the color to filtered icon
        font-size: medium;        // set the font-size to filtered icon
    }
</style>

Blazor DataGrid Customized Filtered Icon

Customize the height and width of filter popup

You can customize the height and width of each column’s filter dialog using the CSS style in the OnActionBegin event of the Grid.

Before opening a filter dialog for each column, the OnActionBegin event will be triggered with the RequestType argument as FilterBeforeOpen. At that point, based on the boolean value, we have set the height and width of the CustomerID and OrderDate columns using the CSS style in the following sample.

@using Syncfusion.Blazor.Grids

<SfGrid ID= "Grid" DataSource="@Orders" AllowFiltering="true">
    <GridEvents OnActionBegin="OnActionBegin" TValue="Order"></GridEvents>
    <GridFilterSettings Type ="Syncfusion.Blazor.Grids.FilterType.Excel"></GridFilterSettings>
    <GridColumns>
        <GridColumn Field=@nameof(Order.OrderID) HeaderText="Order ID" TextAlign="TextAlign.Right" Width="120"></GridColumn>
        <GridColumn Field=@nameof(Order.CustomerID) HeaderText="Customer Name" Width="150"></GridColumn>
        <GridColumn Field=@nameof(Order.OrderDate) HeaderText=" Order Date" Format="d" Type="ColumnType.Date" TextAlign="TextAlign.Right" Width="130"></GridColumn>
        <GridColumn Field=@nameof(Order.Freight) HeaderText="Freight" Format="C2" TextAlign="TextAlign.Right" Width="120"></GridColumn>
    </GridColumns>
</SfGrid>

@if(IsLarge)
{
    <style>
        #Grid .e-excelfilter.e-popup.e-popup-open {
            height: 400px;
            width: 350px !important;
        }
    </style>
}
@if(IsSmall)
{
    <style>
        #Grid .e-excelfilter.e-popup.e-popup-open {
            height: 450px;
            width: 280px !important;
        }
    </style>
}

@code{
    public List<Order> Orders { get; set; }
    public bool IsLarge { get; set; } = false;
    public bool IsSmall { get; set; } = false;
    public void OnActionBegin(ActionEventArgs<Order> Args)
    {
        if (Args.RequestType == Syncfusion.Blazor.Grids.Action.FilterBeforeOpen)
        {
            if(Args.ColumnName == "CustomerID")
            {
                IsLarge = true;
                IsSmall = false;
            }
            else if(Args.ColumnName == "OrderDate")
            {
                IsSmall = true;
                IsLarge = false;
            }
            else
            {
                IsLarge = false;
                IsSmall = false;
            }
        }
    }

    protected override void OnInitialized()
    {
        Orders = Enumerable.Range(1, 75).Select(x => new Order()
            {
                OrderID = 1000 + x,
                CustomerID = (new string[] { "ALFKII", "ANANTR", "ANTON", "BLONP", "BOLID" })[new Random().Next(5)],
                Freight = 2.1 * x,
                OrderDate = (new DateTime[] { new DateTime(2010, 5, 1), new DateTime(2010, 5, 2), new DateTime(2010, 5, 3), })[new Random().Next(3)],
            }).ToList();
    }

    public class Order {
        public int? OrderID { get; set; }
        public string CustomerID { get; set; }
        public DateTime? OrderDate { get; set; }
        public double? Freight { get; set; }
    }
}

Customize the Height and Width of Filter Popup in Blazor DataGrid

NOTE

View Sample in GitHub.
