Open and Save in the Blazor Image Editor component

30 Sep 202415 minutes to read

The Blazor Image Editor component supports to import an image into the canvas, it must first be converted into a blob object. The Uploader component can be used to facilitate the process of uploading an image from the user interface. Once the image has been uploaded, it can then be converted into a blob and drawn onto the canvas.

Supported image formats

The Image Editor control supports three common image formats: PNG, JPEG, and SVG. These formats allow you to work with a wide range of image files within the Image Editor.

When it comes to saving the edited image, the default file type is set as PNG. This means that when you save the edited image without specifying a different file type, it will be saved as a PNG file. However, it’s important to note that the Image Editor typically provides options or methods to specify a different file type if desired. This allows you to save the edited image in formats other than the default PNG, such as JPEG or SVG, based on your specific requirements or preferences.

Open an image

The OpenAsync method in the Blazor Image Editor component offers the capability to open an image by providing it in different formats. This method accepts various types of arguments, such as a base64-encoded string, raw image data, or a hosted/online URL. You can pass either the file name or the actual image data as an argument to the OpenAsync method, and it will load the specified image into the image editor component. This flexibility allows you to work with images from different sources and formats, making it easier to integrate and manipulate images within the Image Editor component.

Note: To load the image in the image editor, the image is placed within the application’s “wwwroot” folder.

@using Syncfusion.Blazor.ImageEditor

<SfImageEditor @ref="ImageEditor" Toolbar="customToolbarItem" Height="400">
    <ImageEditorEvents Created="OpenAsync"></ImageEditorEvents>
</SfImageEditor>

@code {
    SfImageEditor ImageEditor;
    private List<ImageEditorToolbarItemModel> customToolbarItem = new List<ImageEditorToolbarItemModel>() { };

    private async void OpenAsync()
    {
        await ImageEditor.OpenAsync("nature.png");
    }
}

Open an image from Base64 format

Users can easily open images in the Image Editor using a Base64-encoded string. This method allows you to load images directly from their Base64 representation, ensuring seamless integration and flexibility in your application. Simply pass the Base64 string to the OpenAsync method, and the image will be loaded into the editor.

Note: You can obtain the Base64 representation of an image from the Image Editor using the GetImageDataUrlAsync method. This process will be explained in the upcoming section.

@using Syncfusion.Blazor.ImageEditor
<div style="padding-bottom: 15px">
    <SfButton OnClick="SaveAsync">Save</SfButton>
    <SfButton OnClick="OpenBaseAsync">Open base64</SfButton>
</div>
<SfImageEditor @ref="ImageEditor" Height="400">
    <ImageEditorEvents Created="OpenAsync"></ImageEditorEvents>
</SfImageEditor>

@code {
    SfImageEditor ImageEditor;
    private string base64String;

    private async void OpenAsync()
    {
        await ImageEditor.OpenAsync("nature.png");
    }

    private async void SaveAsync()
    {
        var imageData = await ImageEditor.GetImageDataUrlAsync();
        base64String = Convert.ToBase64String(imageData);
    }

    private async void OpenBaseAsync()
    {
    }
}

Open an image from file uploader

User can easily open images in the Image Editor using a file uploader. This method allows users to upload an image file from their device and load it directly into the editor. Once the image is selected through the file uploader, pass the file to the OpenAsync method, and the image will be seamlessly loaded into the editor.

@using Syncfusion.Blazor.Inputs
@using Syncfusion.Blazor.ImageEditor
@using System.IO

<div class="e-img-editor-sample">
    <SfUploader AllowedExtensions=".jpg,.jpeg,.png" AutoUpload="false" @ref="uploader" Selected="@OnImageSelected">
    </SfUploader>
    <SfImageEditor @ref="imageEditor" Height="350px"></SfImageEditor>
</div>

@code {
    private SfUploader uploader;
    private SfImageEditor imageEditor;

    private async Task OnImageSelected(UploadChangeEventArgs args)
    {
        if (args.Files != null && args.Files.Count > 0)
        {
            var file = args.Files[0];
            if (file != null)
            {
                using (var memoryStream = new MemoryStream())
                {
                    await file.File.OpenReadStream(long.MaxValue).CopyToAsync(memoryStream);
                    string base64String = Convert.ToBase64String(memoryStream.ToArray());
                    await imageEditor.OpenAsync(dataUrl);
                }
            }
        }
    }
}

Add Watermarks while opening an image

You can utilize the ‘FileOpenEventArgs’ event, which triggers once the image is loaded into the image editor. After this event, you can use the ‘DrawTextAsync’ method to add a watermark. This approach allows the watermark to be automatically drawn on the canvas every time an image is opened in the editor, making it useful for handling copyright-related content.

@using Syncfusion.Blazor.ImageEditor
<SfImageEditor @ref="ImageEditor" Height="400">
    <ImageEditorEvents Created="OpenAsync" FileOpened="FileOpenedAsync"></ImageEditorEvents>
</SfImageEditor>

@code {
    SfImageEditor ImageEditor;

    private async void OpenAsync()
    {
        await ImageEditor.OpenAsync("nature.png");
    }

    private async void FileOpenedAsync()
    {
       ImageDimension Dimension = await ImageEditor.GetImageDimensionAsync();
        await ImageEditor.DrawTextAsync(Dimension.X.Value + 100, Dimension.Y.Value + 100, "Enter\nText", "Arial", 40, false, false, "#80330075");
    }
}

Save as image

The ExportAsync method in the Blazor Image Editor component is used to save the modified image as an image, and it accepts a file name and file type as parameters. The file type parameter supports PNG, JPEG, and SVG and the default file type is PNG. Users are allowed to save an image with a specified file name, file type, and image quality. This enhancement provides more control over the output, ensuring that users can save their work exactly as they need it.

In the following example, the ExportAsync method is used in the button click event.

@using Syncfusion.Blazor.ImageEditor
@using Syncfusion.Blazor.Buttons

<div style="padding-bottom: 15px">
    <SfButton OnClick="ExportAsync">Export</SfButton>
</div>
<SfImageEditor @ref="ImageEditor" Toolbar="customToolbarItem" Height="400">
    <ImageEditorEvents Created="OpenAsync"></ImageEditorEvents>
</SfImageEditor>

@code {
    SfImageEditor ImageEditor;
    private List<ImageEditorToolbarItemModel> customToolbarItem = new List<ImageEditorToolbarItemModel>() { };

    private async void OpenAsync()
    {
        await ImageEditor.OpenAsync("nature.png");
    }

    private async void ExportAsync()
    {
        await ImageEditor.ExportAsync("Syncfusion", ImageEditorFileType.PNG);
    }
}

Save the image as base64 format.

To save an image as a base64 format, use the GetImageDataUrlAsync method of the editor to retrieve the image data and convert it into a Data URL, which contains the base64-encoded string. By invoking the OpenAsync on the Syncfusion Image Editor instance, you can load this Data URL into the editor. The resulting base64 string can then be embedded directly in HTML or CSS or transmitted over data channels without requiring an external file.

@using Syncfusion.Blazor.ImageEditor
<div style="padding-bottom: 15px">
    <SfButton OnClick="SaveAsync">Save</SfButton>
</div>
<SfImageEditor @ref="ImageEditor" Height="400">
    <ImageEditorEvents Created="OpenAsync"></ImageEditorEvents>
</SfImageEditor>

@code {
    SfImageEditor ImageEditor;
    private string base64String;

    private async void OpenAsync()
    {
        await ImageEditor.OpenAsync("nature.png");
    }

    private async void SaveAsync()
    {
        var imageData = await ImageEditor.GetImageDataUrlAsync();
        base64String = Convert.ToBase64String(imageData);
    }
}

Save the image as byte[]

To save an image as a byte array, use the GetImageDataUrlAsync method of the editor to retrieve the image data and convert it into a byte array. You can then invoke the OpenAsync method on the Syncfusion Image Editor instance to load this byte array into the editor. The resulting byte array can be stored in a database for data management and maintenance.

@using Syncfusion.Blazor.ImageEditor

<SfImageEditor @ref="imageEditor" Height="400px" />

<button @onclick="SaveImageAsByteArray">Save Image</button>
<button @onclick="OpenImage">Open Image</button>

@code {
    private SfImageEditor imageEditor;
    private byte[] savedImageData; // Variable to hold the saved image data

    private async Task SaveImageAsByteArray()
    {
        savedImageData = await imageEditor.GetImageDataAsync();
    }

    private async Task OpenImage()
    {
        if (savedImageData != null)
        {
            string base64String = Convert.ToBase64String(savedImageData);
            await imageEditor.OpenAsync(base64String);
        }
    }
}

Save as image in server

The GetImageDataUrlAsync method in the Blazor Image Editor component is used to gets the current image data url from the Image Editor component

The value returned from this method is used to save the edited image to database as well as open in our image editor using The OpenAsyncmethod.

NOTE

Increase the connection buffer size in Blazor Image Editor component

The Syncfusion’s Blazor Image Editor component allows to increase the connection buffer size by adding the below service in program.cs file if the size of the image is too large.

builder.Services.AddServerSideBlazor().AddHubOptions(o => { o.MaximumReceiveMessageSize = 102400000; });

Remove default Save button and add custom button to save the image to server

User can leverage the Toolbar property to replace the default save button with a custom one. By doing so, you can use the GetImageDataUrlAsync method to retrieve the image data, convert it to base64 format, and then save it to the server. This approach gives you more control over the image-saving process.

@using Syncfusion.Blazor.ImageEditor
@using Syncfusion.Blazor.Navigations

<div>
    <SfImageEditor @ref="ImageEditor" Height="400px" Width="500px" Toolbar="@customToolbar">
    </SfImageEditor>
    <button @onclick="SaveImage">Save to Server</button>
</div>

@code {
    private SfImageEditor ImageEditor;

    // Define the custom toolbar items
    private List<ImageEditorToolbarItemModel> customToolbar = new List<ImageEditorToolbarItemModel>()
    {
        new ImageEditorToolbarItemModel { Name = "Zoom" },
        new ImageEditorToolbarItemModel { Name = "Annotation" },
        new ImageEditorToolbarItemModel { Name = "Filter" },
        new ImageEditorToolbarItemModel { Name = "Crop" },
        new ImageEditorToolbarItemModel { Text = "Rotate", TooltipText = "Rotate", Align = ItemAlign.Center }
    };
    private async Task SaveImage()
    {
        var imageData = await ImageEditor.GetImageDataUrlAsync();
        if (!string.IsNullOrEmpty(imageData) && imageData.Contains(","))
        {
            var base64Data = imageData.Split(',')[1];
            byte[] imageBytes = Convert.FromBase64String(base64Data);
        }
    }
}

Prevent default save option and save the image to specific location

User can make use of the Saving event, which triggers just before the image is downloaded, to override the default save option by setting args.cancel to true. Afterward, you can utilize the GetImageDataUrlAsync method to retrieve the current image data and convert it into a format like byte[], blob, or base64 for further processing. This gives you greater flexibility in handling the image data.

@using Syncfusion.Blazor.ImageEditor
@using System.IO

<div>
<SfImageEditor @ref="ImageEditor" Height="400px" Width="500px">
<ImageEditorEvents Saving="OnBeforeSave"></ImageEditorEvents>
</SfImageEditor>
</div>

@code {
    private SfImageEditor ImageEditor;

    private async Task OnBeforeSave(SaveEventArgs args)
    {
        args.Cancel = true;
        var imageData = await ImageEditor.GetImageDataUrlAsync();
        if (!string.IsNullOrEmpty(imageData) && imageData.Contains(","))
        {
            var base64Data = imageData.Split(',')[1];
            byte[] imageBytes = Convert.FromBase64String(base64Data);
        }
    }
}

Events to handle Save Actions

The Image Editor provides several events related to opening and saving images. These events offer detailed control over the image handling process. For comprehensive information about these events, including their triggers and usage, please refer to the dedicated section on open and save support. This section will provide you with the specifics needed to effectively utilize these events in your application.

File opened event

The FileOpened event is triggered in the Blazor Image Editor component after an image is successfully loaded. It provides the FileOpenEventArgs as the event argument, which contains two specific arguments:

FileName: This argument is a string that contains the file name of the opened image. It represents the name of the file that was selected or provided when loading the image into the Image Editor.

FileType: This argument is a string that contains the type of the opened image. It specifies the format or file type of the image that was loaded, such as PNG, JPEG, or SVG.

By accessing these arguments within the FileOpened event handler, you can retrieve information about the loaded image, such as its file name and file type. This can be useful for performing additional actions or implementing logic based on the specific image that was opened in the Image Editor component.

Saving event

The Saving event is triggered in the Blazor Image Editor component when an image is being saved to the local disk. It provides the SaveEventArgs as the event argument, which includes the following specific arguments:

FileName: This argument is a string that holds the file name of the saved image. It represents the name of the file that will be used when saving the image to the local disk.

FileType: This argument is a string indicating the type or format of the saved image. It specifies the desired file type in which the image will be saved, such as PNG, JPEG, or SVG.

Cancel: This argument is a boolean value that can be set to true in order to cancel the saving action. By default, it is set to false, allowing the saving process to proceed. However, if you want to prevent the saving action from occurring, you can set Cancel to true within the event handler.

By accessing these arguments within the Saving event handler, you can retrieve information about the file name and file type of the image being saved. Additionally, you have the option to cancel the saving action if necessary.

Created event

The Created event is triggered once the Blazor Image Editor component is created. This event serves as a notification that the component has been fully initialized and is ready to be used. It provides a convenient opportunity to render the Image Editor with a predefined set of initial settings, including the image, annotations, and transformations.

In the following example, the Created event is used to load an image.

@using Syncfusion.Blazor.ImageEditor

<SfImageEditor @ref="ImageEditor" Toolbar="customToolbarItem" Height="400">
    <ImageEditorEvents Created="OpenAsync"></ImageEditorEvents>
</SfImageEditor>

@code {
    SfImageEditor ImageEditor;
    private List<ImageEditorToolbarItemModel> customToolbarItem = new List<ImageEditorToolbarItemModel>() { };

    private async void OpenAsync()
    {
        await ImageEditor.OpenAsync("nature.png");
    }
}

Destroyed event

The Destroyed event is triggered once the Blazor Image Editor component is destroyed or removed from the application. This event serves as a notification that the component and its associated resources have been successfully cleaned up and are no longer active.

Reset an image

The ResetAsync method in the Blazor Image Editor component provides the capability to undo all the changes made to an image and revert it back to its original state. This method is particularly useful when multiple adjustments, annotations, or transformations have been applied to an image and you want to start over with the original, unmodified version of the image.

By invoking the ResetAsync method, any modifications or edits made to the image will be undone, and the image will be restored to its initial state. This allows you to easily discard any changes and begin again with the fresh, unaltered image.
