Filtering in Blazor MultiSelect Dropdown Component

24 Jun 202617 minutes to read

The AllowFiltering feature in the Blazor MultiSelect component enables real-time search capability within the dropdown popup. Users can filter the list of items dynamically based on their input, supporting both simple text searches and complex filtered queries.

Getting Started with AllowFiltering

The AllowFiltering property enables or disables the search functionality in the MultiSelect component. When enabled, users can type in the dropdown to filter items that match the search criteria.

Basic Usage

To enable filtering, set the AllowFiltering property to true. By default, this property is set to false.

<SfMultiSelect TItem="string" TValue="string[]" AllowFiltering="true" DataSource="@countries" Placeholder="Select a country">
    <MultiSelectFieldSettings Text="Name" Value="Code"></MultiSelectFieldSettings>
</SfMultiSelect>

@code {
    private string[] countries = new string[] { "Apple", "Banana", "Cherry", "Date", "Grape", "Orange" };
}

In this example, the MultiSelect component displays a list of countries with filtering enabled. When the user types in the search box, the list filters in real-time to show only matching items.

Note: The filtering feature works with both primitive data types (strings, integers) and complex object types when configured with FilterType.

Filtering in Different Visual Modes

The behavior of the filtering feature varies depending on the VisualMode property setting.

CheckBox Mode

In CheckBox mode, the filter input appears as a dedicated search bar at the top of the popup dropdown. This provides a clear separation between the search functionality and the selection interface.

<SfMultiSelect TItem="string" TValue="string[]" AllowFiltering="true" Mode="VisualMode.CheckBox" DataSource="@fruits" Placeholder="Search fruits">
</SfMultiSelect>

@code {
    private string[] fruits = new string[] { "Apple", "Banana", "Cherry", "Mango", "Orange", "Papaya", "Peach" };
}

The filter bar includes the following features when used in CheckBox mode:

Placeholder Text: Customizable using the FilterBarPlaceholder property
Clear Button: Automatically appears when text is entered in the filter input
Mobile Back Button: Displayed on mobile devices when PopupDisplayMode is set to FullScreen

Box, Default, and Delimiter Modes

In Box, Default, and Delimiter modes, the filter functionality integrates directly into the main search input where the selected items are displayed as chips or delimiter-separated values.

<SfMultiSelect TItem="string" TValue="string[]" AllowFiltering="true" Mode="VisualMode.Box" DataSource="@colors" Placeholder="Select colors">
</SfMultiSelect>

@code {
    private string[] colors = new string[] { "Red", "Green", "Blue", "Yellow", "Orange", "Purple" };
}

Note: In these modes, the user must manually clear the input to see the unfiltered list again, as there is no dedicated filter UI element.

Configuring Filter Types

The FilterType property controls how the filtering algorithm matches text. The available filter types are:

FilterType	Description	Example Match
StartsWith	Matches items that begin with the search text	“App” matches “Apple”
Contains	Matches items that contain the search text anywhere	“pp” matches “Apple”
EndsWith	Matches items that end with the search text	“ple” matches “Apple”

Filter Type Example

<SfMultiSelect TItem="string" TValue="string[]" AllowFiltering="true" FilterType="FilterType.Contains" DataSource="@vegetables" Placeholder="Contains...">
</SfMultiSelect>

@code {
    private string[] vegetables = new string[] { "Carrot", "Cabbage", "Broccoli", "Spinach", "Potato" };
}

The default filter type is StartsWith, which provides an autocomplete-style filtering experience. The Contains filter type is most commonly used for flexible search scenarios.

Case Sensitivity and Accent Handling

The MultiSelect filtering feature supports case-insensitive and accent-insensitive filtering through dedicated properties.

Case-Insensitive Filtering

The IgnoreCase property controls whether the filter operation is case-sensitive.

<SfMultiSelect TItem="string" TValue="string[]" AllowFiltering="true" IgnoreCase="true" DataSource="@countries" Placeholder="Search (case-insensitive)">
</SfMultiSelect>

@code {
    private string[] countries = new string[] { "Apple", "Banana", "Cherry", "America", "Australia" };
}

With IgnoreCase="true", typing “apple” matches “Apple”, “APPLE”, and “apple”. When set to false, only exact case matches are returned.

Accent-Insensitive Filtering

The IgnoreAccent property enables filtering that ignores diacritical marks (accents).

<SfMultiSelect TItem="string" TValue="string[]" AllowFiltering="true" IgnoreAccent="true" DataSource="@names" Placeholder="Search names">
</SfMultiSelect>

@code {
    private string[] names = new string[] { "Jose", "José", "Mänge", "Mange", "Zoë", "Zoe" };
}

With IgnoreAccent="true", typing “Jose” matches both “Jose” and “José”. This is particularly useful when working with international data or names with special characters.

Debounce Delay Configuration

The DebounceDelay property specifies the delay in milliseconds before the filter executes after the user stops typing. This prevents excessive filtering operations during rapid typing.

<SfMultiSelect TItem="string" TValue="string[]" AllowFiltering="true" DebounceDelay="500" DataSource="@cities" Placeholder="Search cities (500ms delay)">
</SfMultiSelect>

@code {
    private string[] cities = new string[] { "New York", "New Delhi", "Newcastle", "Newton", "New Orleans" };
}

The default debounce delay is 300 milliseconds. Setting this value to 0 causes filtering to occur on every keystroke, which may impact performance with large datasets or remote data sources.

Note: The DebounceDelay property only takes effect when the AllowFiltering property is set to true.

Filtering with Complex Data

When working with complex object types, you must configure which fields to use for filtering and display using the MultiSelectFieldSettings component.

Complex Data Example

<SfMultiSelect TItem="Employee" TValue="string[]" AllowFiltering="true" DataSource="@employees" Placeholder="Select employee">
    <MultiSelectFieldSettings Text="Name" Value="ID"></MultiSelectFieldSettings>
</SfMultiSelect>

@code {
    private List<Employee> employees = new List<Employee>
    {
        new Employee { ID = "1", Name = "John Smith", Department = "Engineering" },
        new Employee { ID = "2", Name = "James Wilson", Department = "Marketing" },
        new Employee { ID = "3", Name = "Mary Johnson", Department = "Engineering" },
        new Employee { ID = "4", Name = "Michael Brown", Department = "Sales" },
        new Employee { ID = "5", Name = "Jennifer Davis", Department = "HR" }
    };

    public class Employee
    {
        public string ID { get; set; }
        public string Name { get; set; }
        public string Department { get; set; }
    }
}

In this example, filtering occurs based on the Name property as configured in MultiSelectFieldSettings. When the user types “John”, the list filters to show only employees with “John” in their name.

Virtualization with Filtering

The filtering feature works seamlessly with EnableVirtualization for large datasets. When both features are enabled, only the visible items are rendered to the DOM, ensuring optimal performance.

Virtualized Filtering Setup

<SfMultiSelect TItem="Product" TValue="string[]" AllowFiltering="true" EnableVirtualization="true" DataSource="@products" Placeholder="Search products">
    <MultiSelectFieldSettings Text="ProductName" Value="ProductID"></MultiSelectFieldSettings>
</SfMultiSelect>

@code {
    private List<Product> products;

    protected override void OnInitialized()
    {
        products = GenerateProducts(10000);
    }

    private List<Product> GenerateProducts(int count)
    {
        var productList = new List<Product>();
        for (int i = 1; i <= count; i++)
        {
            productList.Add(new Product
            {
                ProductID = i.ToString(),
                ProductName = $"Product {i}"
            });
        }
        return productList;
    }

public class Product
{
    public string ProductID { get; set; }
    public string ProductName { get; set; }
}
}

When virtualization is enabled with filtering:

The component clones the existing query and adds filter conditions
Virtual indices are maintained to track visible items
Skeleton loaders appear while filtered data loads
The GeneratedData dictionary caches results to avoid re-querying

Note: The TotalCount value adjusts during filtering to reflect only the filtered result count rather than the total dataset size.

Filtering with HideSelectedItem

The HideSelectedItem property removes already-selected items from the filtered list. This behavior differs between modes.

HideSelectedItem in Action

<SfMultiSelect TItem="string" TValue="string[]" AllowFiltering="true" HideSelectedItem="true" DataSource="@languages" Placeholder="Select language">
</SfMultiSelect>

@code {
    private string[] languages = new string[] { "CSharp", "JavaScript", "Python", "Java", "TypeScript", "Go" };
}

In Box, Default, and Delimiter modes, selected items are hidden from the dropdown list when filtering. In CheckBox mode, selected items remain visible with checkmarks.

Note: The HideSelectedItem property is ignored in CheckBox mode, where selected items are always displayed with their selection state.

Custom Query Filtering

You can provide a custom base query that filtering will be applied on top of. The component merges the user’s query with filter conditions while preserving the original query settings.

Query with Filtering

<SfMultiSelect TItem="Order" TValue="string[]" AllowFiltering="true" Query="@customQuery" DataSource="@orders" Placeholder="Search orders">
    <MultiSelectFieldSettings Text="OrderName" Value="OrderID"></MultiSelectFieldSettings>
</SfMultiSelect>

@code {
    private Query customQuery = new Query().Where("Status", "equal", "Active").Take(100);

    private List<Order> orders = new List<Order>
    {
        new Order { OrderID = "1", OrderName = "Order A", Status = "Active" },
        new Order { OrderID = "2", OrderName = "Order B", Status = "Inactive" },
        new Order { OrderID = "3", OrderName = "Order C", Status = "Active" }
    };

    public class Order
    {
        public string OrderID { get; set; }
        public string OrderName { get; set; }
        public string Status { get; set; }
    }
}

When filtering is applied with a custom query:

The base query is cloned to preserve original settings
Filter conditions are added without modifying the original query
The Take() method from the user’s query is preserved
Both conditions are applied together in the final query

Filtering Events

The MultiSelect component provides several events for handling filtering operations at different stages.

Filtering Event

The Filtering event fires before the filtering action executes, allowing you to modify or cancel the default filtering behavior.

<SfMultiSelect @ref="MultiSelectRef" TItem="string" TValue="string[]" AllowFiltering="true" DataSource="@items" Filtering="@OnFiltering" Placeholder="Search with custom logic">
</SfMultiSelect>

@code {
    private string[] items = new string[] { "Apple", "Apricot", "Banana", "Cherry", "Avocado" };
    private SfMultiSelect<string[], string> MultiSelectRef;
    private async void OnFiltering(Syncfusion.Blazor.DropDowns.FilteringEventArgs args)
    {
        // Prevent default filtering and apply custom logic
        args.PreventDefaultAction = true;
        // Custom filter: match items that contain the typed text OR start with "A"
        var filtered = items.Where(x => x.Contains(args.Text) || x.StartsWith("A")).ToList();
        await MultiSelectRef.FilterAsync(filtered);
    }
}

Using WhereFilter.Or with Filtering Event

You can construct complex filter conditions using WhereFilter.Or() with a List<WhereFilter> when you need to combine multiple filter criteria with OR logic. This approach is particularly useful when working with remote data sources where you want the filtering to be performed on the server.

<SfMultiSelect TValue="string[]" @ref="mulObj" TItem="Country" Placeholder="e.g. Australia" DataSource="@Countries" AllowFiltering="true">
    <MultiSelectFieldSettings Text="Name" Value="Code"></MultiSelectFieldSettings>
    <MultiSelectEvents TValue="string[]" TItem="Country" Filtering="OnFilter"></MultiSelectEvents>
</SfMultiSelect>

@code {
    SfMultiSelect<string[], Country> mulObj { get; set; }

    public class Country
    {
        public string Name { get; set; }
        public string Code { get; set; }
    }

    List<Country> Countries = new List<Country>
    {
        new Country() { Name = "Australia", Code = "AU" },
        new Country() { Name = "Bermuda", Code = "BM" },
        new Country() { Name = "Canada", Code = "CA" },
        new Country() { Name = "Cameroon", Code = "CM" },
        new Country() { Name = "Denmark", Code = "DK" }
    };

    private async Task OnFilter(Syncfusion.Blazor.DropDowns.FilteringEventArgs args)
    {
        args.PreventDefaultAction = true;
        var predicate = new List<WhereFilter>
        {
            new WhereFilter { Condition = "or", Field = "Name", value = args.Text, Operator = "contains", IgnoreAccent = true, IgnoreCase = true },
            new WhereFilter { Condition = "or", Field = "Code", value = args.Text, Operator = "contains", IgnoreAccent = true, IgnoreCase = true }
        };
        var query = new Query().Where(WhereFilter.Or(predicate));
        query = !string.IsNullOrEmpty(args.Text) ? query : new Query();
        await mulObj.FilterAsync(this.mulObj.DataSource, query);
    }
}

When using WhereFilter.Or():

Property	Description
Condition	Set to `"or"` to combine conditions with OR logic
Field	The property name to filter on (e.g., `"Name"`, `"Code"`)
Operator	The comparison operator (e.g., `"contains"`, `"startswith"`, `"equal"`)
Value	The value to compare against (from `args.Text`)
IgnoreCase	Set to `true` for case-insensitive filtering
IgnoreAccent	Set to `true` for accent-insensitive filtering

Note: The WhereFilter.Or() approach is recommended when working with remote data sources, as the filter query can be sent directly to the server for processing.”

Custom Value Creation with Filtering

When AllowCustomValue is enabled, users can add custom values that do not match any existing items. This is particularly useful when no filter matches are found.

<SfMultiSelect TItem="string" TValue="string[]" AllowFiltering="true" AllowCustomValue="true" DataSource="@colors" Placeholder="Select or add color">
</SfMultiSelect>

@code {
    private string[] colors = new string[] { "Red", "Green", "Blue", "Yellow", "Orange" };
}

With both properties enabled, users can type a custom value (such as “Purple”) that does not exist in the list and add it as a new selection.

No Records Found Behavior

When filtering produces no matching items, the MultiSelect component displays a “No Records” message by default. You can customize this using the NoRecordsTemplate.

Custom No Records Template

<SfMultiSelect TItem="string" TValue="string[]" AllowFiltering="true" DataSource="@countries" Placeholder="Search countries">
    <NoRecordsTemplate>
        <div class="no-records">
            <span>No matching records found</span>
            <button @onclick="ClearFilter">Clear Filter</button>
        </div>
    </NoRecordsTemplate>
</SfMultiSelect>

@code {
    private string[] countries = new string[] { "USA", "UK", "India", "Canada", "Australia" };

    private async Task ClearFilter()
    {
        // Clear the filter and show all items
    }
}

The filtering feature supports comprehensive keyboard navigation for accessibility.

Key	Behavior During Filtering
Typing (a-z, 0-9)	Adds character to filter input and triggers search
Backspace	Removes character from filter and updates results
ArrowDown	Moves focus to next visible item in filtered list
ArrowUp	Moves focus to previous visible item in filtered list
Enter/Space	Selects the focused filtered item
Tab	Moves focus out of filter input and closes popup
Escape	Clears filter input and closes popup

Search docs

Ask Syncfusion AI Assistant

Search docs

Ask Syncfusion AI Assistant

Getting Started with AllowFiltering

Basic Usage

Filtering in Different Visual Modes

CheckBox Mode

Box, Default, and Delimiter Modes

Configuring Filter Types

Filter Type Example

Case Sensitivity and Accent Handling

Case-Insensitive Filtering

Accent-Insensitive Filtering

Debounce Delay Configuration

Filtering with Complex Data

Complex Data Example

Virtualization with Filtering

Virtualized Filtering Setup

Filtering with HideSelectedItem

HideSelectedItem in Action

Custom Query Filtering

Query with Filtering

Filtering Events

Filtering Event

Using WhereFilter.Or with Filtering Event

Custom Value Creation with Filtering

No Records Found Behavior

Custom No Records Template

Keyboard Navigation During Filtering

AllowFiltering in MultiSelect Dropdown

Getting Started with AllowFiltering

Basic Usage

Filtering in Different Visual Modes

CheckBox Mode

Box, Default, and Delimiter Modes

Configuring Filter Types

Filter Type Example

Case Sensitivity and Accent Handling

Case-Insensitive Filtering

Accent-Insensitive Filtering

Debounce Delay Configuration

Filtering with Complex Data

Complex Data Example

Virtualization with Filtering

Virtualized Filtering Setup

Filtering with HideSelectedItem

HideSelectedItem in Action

Custom Query Filtering

Query with Filtering

Filtering Events

Filtering Event

Using WhereFilter.Or with Filtering Event

Custom Value Creation with Filtering

No Records Found Behavior

Custom No Records Template

Keyboard Navigation During Filtering
